Ubit 1-Port RJ45 Gigabit Ethernet PCI-E Network Controller Card(8111G)

Model: 8111G

Main Control Chip:RTL8111G

Network Interface: RJ-45*1

Transmission Rate: 10/100/1000Mbps

Bus Interface: PCI-E (Supports PCI-EX1 X4 X8 X16)

Support System: Windows XP, Windows 7, Windows 8, Windows 8.1, Windows 10, LINUX

Drive Link:

  • Product Description
  • Standard Setting Guide
  • Customer FAQ
  • Driver Download
  • Video
PCI-E Ethernet Gigabit Network Card

Ubit 8111G Gigabit Ethernet PCI-E Network Controller Card 10/100/1000Mbps RJ45 LAN Server Adapter


Port Type: RJ-45

Chipset: RTL 8111G

Supports PCI Express 1.1

Supports full duplex flow control (IEEE 802.3x)

Supports Windows XP/ 2000/ 2008/ Vista/ 7/ 8/ Linux

Supports IEEE 802.3, 802.3ab, 802.3u, 802.3x, 802.1, VLAN

System required: At least one PCI-E x1 slot on the computer

Supports pair swap/polarity/skew correction, crossover detection & auto-correction, wake-on-LAN and remote wake-up

Ubit 1000Mbps RJ-45 Gigabit Network Card Ethernet LAN Adapter Gigabit Network Card

Realtek 8111G Chipset

Ubit 8111G Gigabit Ethernet Network Card --- Using Realtek 8111G Chipset

The Realtek RTL8111G-CG/RTL8111GS-CG 10/100/1000M Ethernet controller combines a triple-speed IEEE 802.3 compatible Media Access Controller (MAC) with a triple-speed Ethernet transceiver, PCI Express bus controller, and embedded memory. With state-of-the-art DSP technology and mixed-mode signal technology, the RTL8111G/RTL8111GS offers high-speed transmission over CAT 5 UTP cable or CAT 3 UTP (10Mbps only) cable. Functions such as Crossover Detection and Auto-Correction, polarity correction, adaptive equalization, cross-talk cancellation, echo cancellation, timing recovery, and error correction are implemented to provide robust transmission and reception capability at high speeds.
